Water Storage Tanks
Water is such a vital part of life on the land, storage must be reliable and long-lasting
West Coast Poly’s agricultural water storage tanks are strong and durable but lightweight enough to move and manage. A great choice for storing stock, spray and household water, and also bore water with high salt and iron content.
West Coast Poly’s 20 Year Manufacturers Guarantee ensures total commitment to the quality and workmanship that goes into your new agricultural water storage tank. Our ISO 9001 Certification & WaterMark accreditation gives added assurance to customers that our service and manufacturing practices are of the highest standards.
Standard fittings are installed into your tank at time of delivery so fit out is to your satisfaction making the tank efficient and easy to use.
RANGE OF WATER TANK PRODUCTS
4,500L to 50,000L
| Volume | Price Inc GST | Diameter | Inlet Height | Overall Height |
|---|---|---|---|---|
| 4500L/1000G | $1,375 | 1.80M | 1.89M | 2.0M |
| 5300L/1175G | $1,595 | 1.93M | 2.07M | 2.07M |
| 9000L/2000G | $2,233 | 2.35M | 2.19M | 2.30M |
| 10000L/2200G | $2,662 | 2.35M | 2.53M | 2.64M |
| 14000L/3100G | $2,871 | 2.85M | 2.34M | 2.45M |
| 23000L/5100G | $3,850 | 3.78M | 2.33M | 2.45M |
| 25000L/5600G | $3,993 | 3.78M | 2.50M | 2.62M |
| 27500L/6100G | $4,631 | 3.78M | 2.75M | 2.87M |
| 38000L/8400G | $7,458 | 4.3M | 3.07M | 3.15M |
| 50000L/11100G | $9,834 | 4.6M | 3.30M | 3.45M |
STANDARD FITTINGS
Installed in tank at time of delivery
All fittings are WaterMark approved
WATER TANK COMBO DEALS
46,000L to 100,000L
| Volume | Price Inc GST | Diameter | Inlet Height | Overall Height |
|---|---|---|---|---|
| 2 x 23000L/5100G | $7,590 | 3.78M | 2.33M | 2.45M |
| 2 x 25000L/5600G | $7,832 | 3.78M | 2.50M | 2.62M |
| 2 x 27500L/6100G | $9,152 | 3.78M | 2.75M | 2.87M |
| 2 x 38000L/8400G | $14,586 | 4.3M | 3.07M | 3.15M |
| 2 x 50000L/11,100G | $19,338 | 4.6M | 3.30M | 3.45M |
***Combo measurements above are per tank.
STANDARD FITTINGS
Installed in tank at time of delivery
All fittings are WaterMark approved
COLOUR RANGE AVAILABLE:
-
SMOOTH CREAM
(Classic Cream®) - WHEAT
-
DESERT HAZE
(Sandbank®) -
WHITE SURFMIST
(Surfmist®) -
MERINO
(Paperbark®) -
DUSK
(Evening Haze®) - BEIGE
-
EARTHTONE
(Bushland®) -
BIRCH GREY
(Dune®) -
INLET
(Cove®) -
RAVINE
(Gully®) -
NATIVE GREY
(Wallaby®) - BASALT
-
AUBERGINE
(Loft®) -
AUTUMN BROWN
(Jasper®) -
TERRANE
(Terrain®) - HERITAGE RED
-
MIST GREEN
(Pale Eucalypt®) -
TIDAL GREEN
(Mangrove®) -
RIVER GUM
(Wilderness®) -
HERITAGE GREEN
(Cottage Green®) - BRONZE OLIVE
- TORRIS BLUE
-
STORMEDGE BLUE
(Blue Ridge®) -
METAL GREY
(Ironstone®) -
MOUNTAIN BLUE
(Deep Ocean®) -
GULL GREY
(Shale Grey®) - LIGHT GREY
- ARMOUR GREY
-
SLATE GREY
(Woodland Grey®) -
CHARCOAL
(Monument®) -
BLACK
(Night Sky®)
Colours shown are an indication only, colours may vary. If colour required not shown, contact us for more options.
STANDARD FITTINGS
Rural range water tanks include Standard Fittings.
The following fitting are included in the price of your tank and will be positioned and installed by our drivers at the time of delivery.
Note: Lifting shackles are included for 50,000L & 38,000L tanks. But are available on request for other sizes.
Mesh Leaf Strainer
90mm Overflow
Screw Top Lid
Philmac Ball Valves
4,500L to 10,000L – 25mm (1”) to 40mm (1.5”)
14,000L to 50,000L – 25mm (1”) to 50mm (2”)
Other sizes available at additional cost.
DR Brass Outlet
4,500L to 10,000L – 25mm (1”) to 40mm (1.5”)
14,000L to 50,000L – 25mm (1”) to 50mm (2”)
Other sizes available at additional cost.
Fittings pictured are for illustration purposes only.
STANDARD FIT-OUT 4,500L – 10,000L
Large Capacity Tanks are delivered via our fleet of trucks within 800km of our Factory and tank fittings are installed onsite at time of delivery.
Extra fittings can also be supplied, a quote can be provided on request.
4,500L – 10,000L
14,000L – 50,000L
ADDITIONAL OPTIONS
COLLECT & PROTECT YOUR RAINWATER
Keep debris & insects out of your rain harvesting system so it stays clean & ensure your water is ready to use through proper filtering.
Leaf Eater Advanced
Carrot Water Diverter
Total Rain
Davy Twin Filter Housings
First Flush Water Diverter
Davey UV Water Disinfection KUV57A
ACCESS & MONITOR YOUR RAINWATER
Fit your tank with larger outlets, connect your tanks or check your tanks water levels at a glance.
Express Tank Gauge
Brass Ball Valves
Hansen Level Alert
Poly Ball Valves
Guided Tank Gauge
Flexible Couplings
ADDITIONAL FITTINGS
Rural range water tanks can be fitted to requirement.
In addition to the standard fittings there are a wide range of sizes and types which may suit your particular situation. Below is a sample of some of the specialised fittings we have available, if you require a particular fitting not shown, let us know to see if we have it available.
DR Brass Outlets
Up to 100mm (4”)
Polyethylene fittings
25mm & 50mm
Camlock Fittings
25mm & 50mm
Float Valves
25mm & 50mm
Atmospheric Vent
100mm Overflow
Fittings pictured are for illustration purposes only.
PUMPS
Davey XP45T
Davey HP65-06T Torrium 2
Davey Firefighter 5113HE
Onga JMP100
Davey HS Series
Davey Firefighter 5265HV
Davey XF171
Aussie QP303
Aussie Fire QP205SE
DELIVERY
Free Delivery is available on the Rural Tank Water Range, Cartage Tanks and Troughs. For more information and details, please see the Delivery Section
Benefits Of A West Coast Poly Tank
Built Tough & Resistant To Corrosion
Mesh Leaf Strainer For Clean Rainwater
UV Resistant & Drinking Water Certified
ADVANCED RIB PROFILE
Bug Proof Over Flow Vent
Customised Tank Fit Out Options
Makes Rain Water Harvesting Simple
High Quality Philmac Ball Valves
WE SET THE STANDARD HIGH
WHY CHOOSE WEST COAST POLY
West Coast Poly has earned an impressive reputation as one of the leading and largest manufacturers of polyethylene storage tanks in Western Australia.
You will be dealing with a company with advanced manufacturing systems and unmatched manufacturing ability.
Talking with experienced local personnel who understand the home-grown conditions for the rural, residential and mining/industrial sectors of Western Australia.
Assured that our service and manufacturing practices are of the highest standards, guaranteeing a top-quality, well-designed product.
INSTALLATION AND MAINTENANCE
The following information is a guide to installing tanks from 4,500 Litre (1,000g) to 50,000 Litre (11,100g)
CRITICAL POINTS TO REMEMBER
- If a sandbase is used we advise that intermittent checks over a period of time should be made for the effects of erosion.
- Base of tank must be fully supported across its entire area (base support must remain flat at all times).
- Failure of the tank due to insufficient base support is not the responsibility of the manufacturer.
- Pipe work should not place any loading on tank wall (flexible coupling is recommended).
- Overflow size must be equal or exceed inlet size.
- Tank must be vented to prevent it being subject to pressure or vacuum (leafstrainer or breather must be installed).
Please note it is the responsibility of the purchaser to ensure the tank base is Compliant with supporting the storage tank and ongoing maintenance. Failure to do so will void the warranty.
